DC DC Power Supply Module HLK-5D1205 1A

2x DC-DC voltage converter 5W, Power supply module, HLK-5D1205 12V to 5V 1a HLK-5D1212 12V ma dc 4: 1

SKU: SLY-HLK-10 Category:

Product Description

Product performance

1. Ultra wide range input (2: 1), 5W output

2. Conversion Efficiency 84% (Typ)

3. Isolation voltage 1500Vdc

4. Ultra-low standby power consumption: 0.3W (typical value)

5. Super fast start: 100mS (typical value)

6. Operating temperature range: -40 ° C ~ + 85 ° C

7.Output short circuit protection, over current protection, over voltage protection

8. Metal shell, low output ripple

9. International standard pins, PCB plug-in installation

10. Adopt high quality environmentally friendly waterproof and thermally conductive adhesive packaging, resistant to moisture and vibration, meet IP65 waterproof and dustproof standard.

11. High reliability, long life design, long continuous working time
